TCS12.7/7.75-57
TCS12.7/7.75-57
Bossed Cast Iron GG20 Triplex Sprockets, 1/2" (12.7mm) Pitch (ISO 08B-3), 8.51mm Roller Diameter
Product specifications
Material
Cast Iron GG20
No. of Teeth [z]
57
ISO No.
08B-3
Pitch/Lead
12.7
Tip Diameter [de]
237.1
Ref. Diameter [dp]
230.54
Hub Diameter [BD]
120
Bore Diameter [di]
25
Sprocket Width [E]
68
Mass kg
13.26
Specifications
Overview
Product specifications
Material
Cast Iron GG20
No. of Teeth [z]
57
ISO No.
08B-3
Pitch/Lead
12.7
Tip Diameter [de]
237.1
Ref. Diameter [dp]
230.54
Hub Diameter [BD]
120
Bore Diameter [di]
25
Sprocket Width [E]
68
Mass kg
13.26
