UCT208

Ondrives Precision Gears and Gearboxes Part number UCT208

UCT208

Cast Iron Takeup Ball Bearing Unit with Set Screws. 12 - 85mm Bores.
Ondrives Precision Gears and Gearboxes Part number UCT208 Ondrives Precision Gears and Gearboxes Part number UCT208

Product specifications

Shaft Diameter40
Dimension [N1]19
Dimension [b]18
Dimension [H2]83
Dimension [N2]49
Dimension [N]29
Dimension [L3]83
Dimension [A1]16
Dimension [H1]102
Dimension [k] [H]114
Dimension [L]144
Dimension [A2]33
Dimension [A]49
Dimension [r]56
Dimension [L1]88
Dimension [B]49.2
Dimension [S]19
Dynamic Load Rating [N]29100
Static Load Rating [N]17900
Mass [kg]2.4

Product specifications

Shaft Diameter40
Dimension [N1]19
Dimension [b]18
Dimension [H2]83
Dimension [N2]49
Dimension [N]29
Dimension [L3]83
Dimension [A1]16
Dimension [H1]102
Dimension [k] [H]114
Dimension [L]144
Dimension [A2]33
Dimension [A]49
Dimension [r]56
Dimension [L1]88
Dimension [B]49.2
Dimension [S]19
Dynamic Load Rating [N]29100
Static Load Rating [N]17900
Mass [kg]2.4
