UCT203

Ondrives Precision Gears and Gearboxes Part number UCT203

UCT203

Cast Iron Takeup Ball Bearing Unit with Set Screws. 12 - 85mm Bores.
Ondrives Precision Gears and Gearboxes Part number UCT203 Ondrives Precision Gears and Gearboxes Part number UCT203

Product specifications

Shaft Diameter17
Dimension [N1]16
Dimension [b]12
Dimension [H2]51
Dimension [N2]32
Dimension [N]19
Dimension [L3]51
Dimension [A1]12
Dimension [H1]76
Dimension [k] [H]89
Dimension [L]94
Dimension [A2]21
Dimension [A]32
Dimension [r]33
Dimension [L1]61
Dimension [B]31
Dimension [S]12.7
Dynamic Load Rating [N]12800
Static Load Rating [N]6600
Mass [kg]0.6

Product specifications

Shaft Diameter17
Dimension [N1]16
Dimension [b]12
Dimension [H2]51
Dimension [N2]32
Dimension [N]19
Dimension [L3]51
Dimension [A1]12
Dimension [H1]76
Dimension [k] [H]89
Dimension [L]94
Dimension [A2]21
Dimension [A]32
Dimension [r]33
Dimension [L1]61
Dimension [B]31
Dimension [S]12.7
Dynamic Load Rating [N]12800
Static Load Rating [N]6600
Mass [kg]0.6
