601XZZ

Ondrives Precision Gears and Gearboxes Part number 601XZZ

601XZZ

Steel Miniature Ball Bearing. Metal Shielded Type ZZ. 1.5mm Bore
Ondrives Precision Gears and Gearboxes Part number 601XZZ Ondrives Precision Gears and Gearboxes Part number 601XZZ

Product specifications

Bore Diameter [d]1.5
Diameter [A]6
Dimension [B]3
Dimension [r] Min.0.15
Static Load Rating [N]98
Dynamic Load Rating [N]324
Max. Speed [rpm]75000

Product specifications

Bore Diameter [d]1.5
Diameter [A]6
Dimension [B]3
Dimension [r] Min.0.15
Static Load Rating [N]98
Dynamic Load Rating [N]324
Max. Speed [rpm]75000
