Gear Ratio [i=] | 1:1 |
Nom Output Torque T₂n [Nm] | 50 |
Nom. Input Speed S5 T₂n [n1nom] | 1500 min-1 (r/min) |
Max. Input Speed [n1max] | 5500 min-1 (r/min) |
Output Backlash j | ≤0.16° |
Efficiency n1nom [ηz] | ≈98% |
Reflected Inertia at Input (kg•m²) | 0.0004545 |
Mass [kg] | 6.7 |
Max. Input Radial Load Fr1 N | 1500 |
Max. Output Radial Load Fr2 N | 1750 |
Max. Input Axial Load Fa1 N | 750 |
Max. Output Axial Load Fa2 N | 1000 |
Lubrication Oil | Klubersynth GH 6-220 |
Max. Operating Temp of Lub | ≈95°C |
Thermal Rating S1 Pthermal [kw] | 5 |
Seals | Fluoro-Elastomer FPM ISO 1629 /FKM ASTM D141 H |
Ingress Protection | IP64 |
Noise Level Low Load | ≈75dB(A) |
