PFN40 18Nm-IP66 37.5mm-Centres
Precision Worm Wheel Reducers
Manufactured by Ondrives in the UK
| Sku (Part No.) | Gear Ratio [i=] | Output Torque T₂n [Nm] | Output Backlash j |
|---|---|---|---|
| PFN40-10 | 10:1 | 7.10 | ≤0.16° |
| PFN40-12 | 12:1 | 7.50 | ≤0.16° |
| PFN40-15 | 15:1 | 8.00 | ≤0.16° |
| PFN40-20 | 20:1 | 8.20 | ≤0.16° |
| PFN40-30 | 30:1 | 9.00 | ≤0.16° |
| PFN40-60 | 60:1 | 10.00 | ≤0.16° |
| PFN40-120 | 120:1 | 8.70 | ≤0.16° |
| PFN40-10A | 10:1 | 7.10 | ≤0.08° |
| PFN40-12A | 12:1 | 7.50 | ≤0.08° |
| PFN40-15A | 15:1 | 8.00 | ≤0.08° |
| PFN40-20A | 20:1 | 8.20 | ≤0.08° |
| PFN40-30A | 30:1 | 9.00 | ≤0.08° |
| PFN40-60A | 60:1 | 10.00 | ≤0.08° |
| PFN40-120A | 120:1 | 8.70 | ≤0.08° |
