| Diameter [D] | 94 |
| Dimension [L] | 142 |
| Min. Bore Diameter [D1] H7 | 19 |
| Max. Bore Diameter [D1] H7 | 38 |
| Min. Bore Diameter [D2] H7 | 14 |
| Max. Bore Diameter [D2] H7 | 38 |
| Diameter [D3] | 65 |
| Diameter [D4] | 82 |
| Thread [M] DIN 912 | M10 |
| Tightening Torque TA Nm [M] | 72 |
| Thread [M1] DIN 912 | M8 |
| Tightening Torque TA Nm [M1] | 25 |
| Dimension [L1] | 59 |
| Dimension [t] | 2 |
| Max. Speed [rpm] | 6030 |
| Mass [kg] | 3.1 |
| Moment of Inertia J Kg cm² | 27 |
| Torque (Nm) | 160 |
| Adjustable Overload Torque TKN (Nm) | 50-130 |
| Radial Misalignment ∆Kr (mm) | 0.11 |
| Axial Misalignment ∆Ka (mm) | 1.5 |
| Angular Misalignment ∆Kw (°) | 0.9° |
