| Diameter [D] | 49 |
| Dimension [L] | 65 |
| Min. Bore Diameter [D1] H7 | 4 |
| Max. Bore Diameter [D1] H7 | 16 |
| Min. Bore Diameter [D2] H7 | 6 |
| Max. Bore Diameter [D2] H7 | 20 |
| Diameter [D3] | 30 |
| Diameter [D4] | 42 |
| Thread [M] DIN 912 | M4 |
| Tightening Torque TA Nm [M] | 5.1 |
| Thread [M1] DIN 912 | M3 |
| Tightening Torque TA Nm [M1] | 1.4 |
| Dimension [L1] | 24 |
| Dimension [t] | 0.7 |
| Max. Speed [rpm] | 11690 |
| Mass [kg] | 0.24 |
| Moment of Inertia J Kg cm² | 0.6 |
| Torque (Nm) | 12.5 |
| Adjustable Overload Torque TKN (Nm) | 3-7 |
| Radial Misalignment ∆Kr (mm) | 0.09 |
| Axial Misalignment ∆Ka (mm) | 1 |
| Angular Misalignment ∆Kw (°) | 0.9° |
