| Torque (Nm) | 2 |
| Dimension [L] ±1 | 42 |
| Diameter [A] | 25 |
| Min. Bore Diameter [D1] & [D2] H7 | 3 |
| Max. Bore Diameter [D1] & [D2] H7 | 14 |
| Dimension [k] [H] | 9 |
| Dimension [C] | 3.5 |
| Diameter [B] | 27 |
| Dimension [E] | 11 |
| DImension [H] | 9 |
| Thread [d] | M3 |
| Tightening Torque TA Nm | 2 |
| Mass (g) | 33 |
| Moment of Inertia J g cm² | 29 |
| Spring Stiffness Torsional Ct Nm/rad | 1050 |
| Spring Stiffness Radial CR N/Nm | 11 |
| Spring Stiffness Axial CA N/mm | 9 |
| Radial Misalignment ∆Kr (mm) | 0.25 |
| Axial Misalignment ∆Ka (mm) | 0.5 |
| Angular Misalignment ∆Kw (°) | 2.0° |
