Torque (Nm) | 4.5 |
Dimension [L] ±1 | 48 |
Diameter [A] | 32 |
Min. Bore Diameter [D1] & [D2] H7 | 6 |
Max. Bore Diameter [D1] & [D2] H7 | 18 |
Diameter [B] | 29 |
Dimension [C] | 4 |
Dimension [E] | 12 |
Thread [d] | M6 |
Tightening Torque TA Nm | 3 |
Mass (g) | 50 |
Moment of Inertia J g cm² | 79.00 |
Spring Stiffness Torsional Ct Nm/rad | 4200 |
Spring Stiffness Radial CR N/Nm | 41 |
Spring Stiffness Axial CA N/mm | 20 |
Radial Misalignment ∆Kr (mm) | 0.2 |
Axial Misalignment ∆Ka (mm) | 0.5 |
Angular Misalignment ∆Kw (°) | 2.0° |
