Torque (Nm) | 1.5 |
Dimension [L] ±1 | 26 |
Diameter [A] | 19 |
Min. Bore Diameter [D1] & [D2] H7 | 3 |
Max. Bore Diameter [D1] & [D2] H7 | 12 |
Diameter [B] | 19 |
Dimension [C] | 3 |
Dimension [E] | 8 |
Thread [d] | M4 |
Tightening Torque TA Nm | 1.5 |
Mass (g) | 10 |
Moment of Inertia J g cm² | 6.00 |
Spring Stiffness Torsional Ct Nm/rad | 750 |
Spring Stiffness Radial CR N/Nm | 59 |
Spring Stiffness Axial CA N/mm | 15 |
Radial Misalignment ∆Kr (mm) | 0.1 |
Axial Misalignment ∆Ka (mm) | 0.3 |
Angular Misalignment ∆Kw (°) | 1.5° |
