Torque (Nm) | 10 |
Dimension [L] ±1 | 55 |
Diameter [A] | 40 |
Min. Bore Diameter [D1] & [D2] H7 | 6 |
Max. Bore Diameter [D1] & [D2] H7 | 24 |
Diameter [B] | 36 |
Dimension [C] | 4 |
Dimension [E] | 12 |
Thread [d] | M6 |
Tightening Torque TA Nm | 3 |
Mass (g) | 79 |
Moment of Inertia J g cm² | 210 |
Spring Stiffness Torsional Ct Nm/rad | 6800 |
Spring Stiffness Radial CR N/Nm | 29 |
Spring Stiffness Axial CA N/mm | 17 |
Radial Misalignment ∆Kr (mm) | 0.3 |
Axial Misalignment ∆Ka (mm) | 0.6 |
Angular Misalignment ∆Kw (°) | 2.0° |
