Torque (Nm) | 0.1 |
Dimension [L] ±1 | 23 |
Diameter [A] | 10 |
Min. Bore Diameter [D1] & [D2] H7 | 1 |
Max. Bore Diameter [D1] & [D2] H7 | 4 |
Diameter [B] | 10 |
Dimension [C] | 2 |
Dimension [E] | 6 |
Thread [d] | M3 |
Tightening Torque TA Nm | 0.5 |
Mass (g) | 3 |
Moment of Inertia J g cm² | 0.45 |
Spring Stiffness Torsional Ct Nm/rad | 65 |
Spring Stiffness Radial CR N/Nm | 10 |
Spring Stiffness Axial CA N/mm | 14 |
Radial Misalignment ∆Kr (mm) | 0.12 |
Axial Misalignment ∆Ka (mm) | 0.2 |
Angular Misalignment ∆Kw (°) | 1.2° |
