KMT12

Ondrives Precision Gears and Gearboxes Part number KMT12

KMT12

High Precision Bearing Locknut, M60
Ondrives Precision Gears and Gearboxes Part number KMT12 Ondrives Precision Gears and Gearboxes Part number KMT12 Ondrives Precision Gears and Gearboxes Part number KMT12

Product specifications

Thread [M x P]M60 x 2
Diameter [D]90
Diameter [D1]82
Diameter [D2]62
Diameter [D3]78
Dimension [k] [H]26
Dimension [S]8
Dimension [T]3.5
Dimension [W]85
Static Axial Load Carrying Capacity [kN]380
Mass [kg]0.61
GrubscrewM8
Recommended Grubscrew Tightening Torque [Nm]18

Product specifications

Thread [M x P]M60 x 2
Diameter [D]90
Diameter [D1]82
Diameter [D2]62
Diameter [D3]78
Dimension [k] [H]26
Dimension [S]8
Dimension [T]3.5
Dimension [W]85
Static Axial Load Carrying Capacity [kN]380
Mass [kg]0.61
GrubscrewM8
Recommended Grubscrew Tightening Torque [Nm]18
