SC30-30/30

Ondrives Precision Gears and Gearboxes Part number SC30-30/30

SC30-30/30

Solid Mild Steel Shaft Coupling, Set Screw Fixing
Ondrives Precision Gears and Gearboxes Part number SC30-30/30 Ondrives Precision Gears and Gearboxes Part number SC30-30/30

Product specifications

MaterialMild Steel
Coupling Configuration1 Piece
Mass (g)1800
Diameter [D]70
Dimension [L]80
Bore Diameter [B]30
Max. Bore Diameter [B]43.0
Bore Diameter [b] H830
Set ScrewM8
Moment of Inertia kg•m²1.33 x 10-3

Product specifications

MaterialMild Steel
Coupling Configuration1 Piece
Mass (g)1800
Diameter [D]70
Dimension [L]80
Bore Diameter [B]30
Max. Bore Diameter [B]43.0
Bore Diameter [b] H830
Set ScrewM8
Moment of Inertia kg•m²1.33 x 10-3
