SC20-15/15

Ondrives Precision Gears and Gearboxes Part number SC20-15/15

SC20-15/15

Solid Mild Steel Shaft Coupling, Set Screw Fixing
Ondrives Precision Gears and Gearboxes Part number SC20-15/15 Ondrives Precision Gears and Gearboxes Part number SC20-15/15

Product specifications

MaterialMild Steel
Coupling Configuration1 Piece
Diameter [D]50
Dimension [L]65
Bore Diameter [B]15
Max. Bore Diameter [B]25
Bore Diameter [b] H815
Set ScrewM6
Moment of Inertia kg•m²2.81 x 10-4

Product specifications

MaterialMild Steel
Coupling Configuration1 Piece
Diameter [D]50
Dimension [L]65
Bore Diameter [B]15
Max. Bore Diameter [B]25
Bore Diameter [b] H815
Set ScrewM6
Moment of Inertia kg•m²2.81 x 10-4
